ISUZ ELF Cargo Truck Mounted Crane Straight Boom 2/3.2 Tons Isuzu Loader Crane Truck for Sale
ISUZ ELF Cargo Truck Mounted Crane Straight Boom 2/3.2 Tons Isuzu Loader Crane Truck for Sale
Japan ELF Cargo Truck Mounted Crane Straight Boom 2/3.2 Tons Isuzu Loader Crane Truck knuckle boom crane truck for sale
| General Specification | |
| Name | ISU-ZU 2/3.2 Tons picker truck mounted crane |
| Applicable crane | 2-3.2 T |
| Gross weight | 4495kg |
| Curb weight | 3410kg |
| Dimension | 5995X2660X2900mm |
| Cargo body dimension | 3590X1850X400mm |
| Wheelbase | 3360mm |
| Drive type | 4X2 |
| Max speed | 95km/h |
| Tire specification | 7 |
| Tire quantity | 6 |
| Brake system | Oil brake |
| Cab | single cab, 2 crew seat |
| EngineSpecification | |
| Engine manufacture | ISUZU |
| Emission standard | Euro 3 |
| Horse power | 95hp |
| Displacement | 2771ml |
| Crane Specification | ||||
| Items | 2-ton 2 section | 2- ton 3 section | 3.2-ton 2 section | 3.2-ton 3 section |
| Max lifting capacity(kg) | 2000 | 2000 | 3200 | 3200 kg |
| Max lifting capacity at full extension(kg) | 400 | 255 | 950 | 500 |
| Working radius(m) | 5.8 | 7.7 | 5.5 | 7.5 |
| Max lifting height(m) | 6.8 | 9 | 6.8 | 9.5 |
| Crane weight(kg) | 875 | 950 | 1105 | 1229 |
| Outrigger span(m) | 1874--3024 | 1874-3024 | 1989--3329 | 1989--3329 |
| Rotation angle | 360 full rotation | 360 full rotation | 360 full rotation | 360 full rotation |
